Approval Standard
1. 1996 amendment to the international convention for the safety of life at sea, 1974
2. MSC48.(66) International Life-saving Appliance Code (LSA Code) and MSC.218(82)、MSC.293(87)
3. Sections Ⅻ of Parts1; Sections Ⅶ of Parts 2of MSC.81(70) Revised Recommendation on Testing of Life-saving Appliances and MSC.226(82)、MSC.295(87)、MSC323.(89)
4. China MSA“Regulations for the Statutory Surveys of Ships and Offshore Installations-Technical Regulations for the Statutory Surveys of Sea-going ships Engaged in Domestic Voyages”2011, Part4, Ch.3 and Revision 2012
Approved by CCS.

Type Name

YL-MES-2I-700-X(4.4-12)

Certification Number of Persons of System

700

Number of Persons Carried by Platform

100

Physical form of platform

Rectangular dodecagon

Dimension of platform(±0100 mm)

9450×6000

Max. height of stowage above the waterline(m)

12

Specification of cylinder of platform

18×4

Gas volume of platform
g

CO2, ±050

10000

N2, ±020

1000
